Electrically Operated Hydraulic Power Packs (Portable Type) (700KgCm2)
- OEW offers a complete range of Portable Modular Electric Pumps to suit al industrial applications.
- Pumps are available in single and two stage models.
- All Pumps come equipped with Pressure Relief Valves for safety.
- Tank : Aluminium casting/ Steel fabricated.
- All Tanks are electrostatic powder coated.
- All Power Pack Components suitably fitted for out door duty.
- Extra Relief Valve provided in reservoir to prevent over loading.
- Return Line Filter provided in only Double Acting Cylinder type Power Packs.
- Standard supply with fixed frame mounted (2 fixed & 2 movable wheel can be provided on request).
- Other sizes (higher flow capacities) available on request.
| FLOW AT RATED PRESSURE (I/MIN.) | 0.5, 1.0, 1.5 |
|---|---|
| MOTOR RATING (HP/ KW) | 1/0.75, 2/1.5, 3/2.2 |
Dimensions Chart
